TeSys Deca contactor 3P 95A AC-3440V - aux 1NO+1NC - Bobina 230V 50Hz Schneider LC1D95P5

Producator:  SCHNEIDER

Descriere produs: TeSys Deca contactor,, 3 poles (3NO), for motor control applications up to 95A/1000V AC-3 (45kW@400V). It provides a 230V 50Hz AC coil, 1NO+1NC built-in auxiliary contacts, power connection by screw terminals and control by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (85mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
