Intreruptor NSX160 3P 36K Micrologic 4.2 100A Schneider LV433828

Name: Intreruptor NSX160 3P 36K Micrologic 4.2 100A Schneider LV433828
Brand: SCHNEIDER
SKU: LV433828
Availability: OutOfStock
Rating: 5 (1 reviews)

Cod Produs: LV433828

Stoc indisponibil

Fisa tehnica

Producator: SCHNEIDER

Descriere produs: This Compact NSX160F is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a 100A rating electronic Micrologic 4.2 Vigi trip unit, with an integrated adjustable earth-leakage protection. Micrologic 4.2 Vigi provides also adjustable long time and short time protections, and a fixed instantaneous protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX160F is part of Schneider Electric EcoStruxure Power architecture.
