Intreruptor Auto Compact Nsx250R - Micrologic 6.2 E-M - 150 A - 3 Poli 3D Schneider LV433530

Citeste mai mult
  • Disponibilitate: In stoc furnizor, livrabil în 7-9 zile lucrătoare, termen estimativ
  • Brand: SCHNEIDER
  • Cod: LV433530
  • Cantitate minim comandata: 1 BUC
  • UM: BUC
  • Descriere produs: This Compact NSX250R is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for motor protection applications. The breaking capacity (Icu) is 200kA rms at 415VAC 50/60Hz and 45kA rms at 690VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 150A rating electronic Micrologic 6.2 E-M trip unit, with an adjustable ground-fault protection (with OFF position). Micrologic 6.2 E-M trip unit provides adjustable long time and short time protections, and fixed instantaneous protection. Micrologic 6.2 E-M has an embedded display unit for fine settings adjustment and display of the energy (energy meter). This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX250R is part of Schneider Electric EcoStruxure Power architecture.
5.274,30 Lei
